NSX100F Compact MCCB

Get a Price/Quote

MOQ : 10 Pieces

NSX100F Compact MCCB Specification

Breaking Capacity
36 kA

Rated Short Circuit Breaking Current
36 kA

Phase
Three Phase

Rated Short Circuit Making Current
36 kA

Mechanical Life
20,000 Operations

Product Type
Compact MCCB

Installation Options
Manual

Function
Overload & Short Circuit Protection

Poles Number
3

Rated Voltage
220-440 Volt (V)

Rated Current
100A

Rated Frequency
50-60 Hertz (HZ)

Curves
Type F

Temperature Protection
Yes

Weight
0.8 kg

Color
Black

Dimensions
140 mm x 105 mm x 85 mm

Isolation Capability
Yes

Trip Unit Type
Thermal-Magnetic

Endurance (Electrical Life)
8,500 Operations

Utilization Category
A

Terminal Connection
Screw/bolt type

Operating Temperature
-5°C to +55°C

Mounting
Panel/Flush

Accessory Options
Auxiliary Contact, Alarm Contact

Frame Size
NSX100

Protection Degree
IP20

NSX100F Compact MCCB Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About NSX100F Compact MCCB

Markdown your electrical projects with the featured NSX100F Compact MCCBa noble and triumphant solution for safety and reliability. This celebrated 3-pole breaker delivers outstanding protection with 36 kA breaking capacity and thermal-magnetic trip units. Compliant with IEC 60947-2 and boasting an IP20 rated build, the NSX100F is perfectly engineered for seamless panel or flush mounting. For a limited time, capitalize on its lightweight, compact frame and integrated manual options. Accessory integration, such as auxiliary and alarm contacts, elevates your installations to new heights.

Versatile Application & Use Cases for NSX100F Compact MCCB

The NSX100F Compact MCCB is ideal for commercial buildings, industrial facilities, and infrastructure projects, ensuring robust overload and short circuit protection. Designed for three-phase applications, this MCCB is used in power distribution panels and automated control systems. Its Type F curve and thermal-magnetic trip unit make it suitable for both continuous and intermittent use, protecting equipment and ensuring system reliability where safety is paramount.

Sample Availability & Export Markets for NSX100F Compact MCCB

Unlock a celebrated deal on the NSX100F Compact MCCB with sample units available to evaluate quality before purchase. Favorably positioned in the domestic and global market, this MCCB is featured at a competitive sale price. It is carefully packaged to maintain integrity during transit, serving main export markets across Asia, Africa, and the Middle East. The products market value is upheld by superior endurance and compliance, attracting buyers worldwide.

FAQs of NSX100F Compact MCCB:

Q: How does the NSX100F Compact MCCB protect electrical systems?

A: The NSX100F Compact MCCB safeguards systems by providing overload and short circuit protection through its thermal-magnetic trip unit, ensuring equipment and personnel safety during abnormal conditions.

Q: What are the main usage scenarios for the NSX100F?

A: This device is primarily used in commercial, industrial, and infrastructure settings to control and protect power distribution in three-phase electrical networks.

Q: Where can the NSX100F Compact MCCB be installed?

A: The MCCB supports panel and flush mounting, offering installation flexibility in various switchboards, control panels, and power distribution cabinets.

Q: When should users consider requesting a sample unit?

A: Requesting a sample is recommended before bulk purchasing to assess compatibility with your specific application and to evaluate product quality firsthand.

Q: What benefits do the accessory options provide?

A: Accessory options like auxiliary and alarm contacts enable enhanced system monitoring and automation, elevating the operational efficiency and safety of your electrical installations.

Q: How is the NSX100F Compact MCCB packaged for export?

A: Each unit is securely packaged to prevent damage, ensuring it arrives in optimal condition whether shipped domestically or exported to major international markets.
